$600.00
Smart Battery System for Professional UAS Operators
High Power varient (heavy lift applications)
High Capacity varient (long range applications)
BMS Feaures:
- Cell Balancing
- Simple no-buttons charging, use a DroneCAN charger or the chargers we offer
- Overload, under and over charge, under and over temp warnings
Telemetry Features:
- Native DroneCAN and UAVCAN v0,v1 support
- Auto detect CAN plugin
- BatteryInfo AP message
- Cell Voltage message
- Working with dev team on additional parameters
Case Features:
- Kevlar inner liner for crash protection
- Carbon exterior for ridigity and sheild against magnetic interference
- Standardized inteface for Drone Battery Dock compatibility
Thermal Regulation Features:
- All weather operation
- Up to 60C operating environment
- Down to -17C with documented startup procedure
Weight: 999 grams
Size (mm): 185 L x 53 W x 75 T
Connection type:
XT90i with built in CAN
Important: Requires adequate airflow during use and charging. Always monitor cell temperatures and follow safe charging practices.
Technical Specifications
| Capacity | 0Ah / 0 Wh |
| Never exceed °C during charge or discharge. Discharge ratings are determined under controlled airflow conditions. | |
|
Discharge Power (Cell Spec) |
0W |
|
Discharge Current (Cell Spec) |
0A |
| Charge Rate Normal | 0A |
| Configuration | 0S0P |
