RED V3 4S2P 6Ah Molicel P30B

$125.00
Skip to product information
RED V3 4S2P 6Ah Molicel P30B — High Power battery, black JST-XH balance connector, leads facing left
RED V3 4S2P 6Ah Molicel P30B

RED V3 4S2P 6Ah Molicel P30B
RD0402-186020a
$125.00

All products are made to order. Current lead time is 4-5 weeks. Orders over 15 quantity may take extra time to process.

RED V3 4S2P High Power battery pack built with Molicel P30B cells, with 6 Ah capacity and 14.4 V nominal voltage.

Specifications

Configuration 4S2P
Cell Molicel P30B
Cell format 18650
Form factor Standard
Capacity 6 Ah
Nominal energy 86.4 Wh
Nominal voltage 14.4 V
Maximum charge voltage 16.8 V
Minimum pack voltage 10.2 V
Recommended landing voltage 10.8 V
Continuous power 249.52 W
Continuous current 18.24 A
10-second burst power 552.96 W
10-second burst current 38.4 A
2-minute burst current 26.88 A
Charge current 4.8 A (0.8C)
Dimensions (L × W × H) 14.4 × 3.8 × 3.8 cm
Pack weight 386 g
Energy density 223.83 Wh/kg
Balance connector JST-XHP-5
Maximum pack temperature 80 °C

Connector options

  • XT60 — RD0402-186020a

Use a suitable balance charger and monitor individual series-group voltages. Pack voltage alone does not verify every series cell group remains within its limits. The 80 °C maximum is a pack temperature limit, not an ambient-temperature rating or a charging temperature allowance.

Documents
Important: Requires adequate airflow during use and charging. Always monitor cell temperatures and follow safe charging practices.
